PMB high voltage power supply

1. Models from1kV to 30kV, 5W, 10W, 20W

2. Low output ripple and noise ＜0.001% P-P

3. High stability 25ppm per hour

4. Low temperature coefficient 25ppm/℃

5. Arc and Short Circuit Protected

6. External potentiometer or external control voltage to set.

7. Optional RS-232, RS-485 control, address can be set and research

8. Positive or negative output

9. Small size, Low noise , six -sided metal shielding

10. OEM customization available

INTRODUCTION

Wisman’s PMB module is a special ultra-low noise, high stability, low ripple, and miniaturized module for photomultiplier tubes, mass spectrometers, and electron microscopes. The price is advantageous. When digital RS232, RS485 control and RS-485 bus are optional, each high-voltage power supply can set an address, with addressing function.

PMB series is with linear + switch structure, small size, low ripple 5mV, high stability, 25ppm low temperature drift, 10ppm optional, six-sided shielding and ultra-low noise. They have the function of overcurrent, short circuit, and arc fault protection.

APPLICATIONS
Mass spectrometry
Photomultiplier Tubes(PMT)
Microchannel plates(MCP)
Proportional Counters
GM Tube
Avalanche Photo Diode (APD)
Solid state detectors
Ionization Chambers
gas chromatography
Electron multiplier
Detectors
Nuclear Instruments
Electrophoresis
DNA sequencing
Radiation counter
Electron Beam
Ion Beam,High
voltage bias
Hipot Testing
Precision Lenses Image Intensifiers
Semicon-ductor Testing
Electrostatic discharge Testing
Provides power to the pulse power
Capacitor Discharging
Life Sciences
Medical chemical Applications
Science
Laboratory Applications
Industrial Applications
