XRH Series X Ray Generator

1. Models from 160KV to 200kV,80W to 640W

2. Integrated Filament Supply 5A@10Vdc

3. Integrated Grid Supply 1200Vdc

4. low output ripple and noise ＜0.1%p-p

5. high stability 0.02%/8 hour

6. low temperature coefficient 25ppm/℃

7. Optional Ethernet, RS-232, RS485 Digital Interfaces

8. Overvoltage, Arc and short circuit Protected

9. Voltage and current adjustment function

10. Local or remote control, or digital control

11. Safety interlock function

12. OEM customization available

13.For micro-focus X-ray tube, open micro-focus X-ray tube

INTRODUCTION:

Wisman’s XRH series x-ray generator is a low-noise microfocus x-ray tube power supply with output power of 80W~640W and output voltage up to 180kV. These light weight rack-mount-able X-ray generator house a miniaturized high voltage system in a solid encapsulated design. Wisman’s XRH series x-ray adopts an input power factor correction circuit, thereby reducing the requirement for input current and at the same time minimizing line-related EMI interference. Wisman’s XRH series x-ray generator adopts wisman’s unique high-voltage floating technology, which integrates the floating filament and grid supply. Wisman’s XRH series x-ray generator incorporates an internal floating filament and a closed-loop emission control circuit for precise regulation of emission current,providing remote monitoring and control of voltage, current and filament current.

APPLICATION:

X-ray Inspection,Non-destructive Testing,Micro-focus spot X-ray tube,X-ray imaging.
